Check sole support at the beginning and end of the pass, not only the board length. A small workpiece must still allow clamping clear of the cutter and two-hand tool control; a helper hand cannot replace a clamp.
This reference material was written and revised with AI. It has not been verified or approved by a professional. Review by a suitably qualified professional and required site approval are necessary before field use.
Stop before proceeding
Hold for uncertain stock clamping, cutter condition or electrical protection. Stop, wait and disconnect after impact, abnormal vibration, overload, new ridges or blocked chips. Do not inspect the underside while power remains connected.
1. Legal and technical scope
For general-industry portable tools, 1910.243 covers applicable controls and guarding; its planer control provision does not impose a universal dead-man switch. Construction use requires applicable Part 1926 controls. CCOHS is Canadian technical guidance, not US law or a substitute for actual stock and planer limits. Dust, noise and any respiratory protection require the applicable workplace assessment and program.
Confirm whether federal OSHA or an OSHA-approved State Plan covers this employer and worksite; state requirements and public-sector coverage can differ. Apply the task-specific provisions and limitations identified above.
| Basis | Application |
|---|---|
| OSHA 29 CFR 1910.243 | Portable powered tools; paragraph (a)(2)(iii) includes planers in its permitted control options. |
| CCOHS portable planers | Power disconnection, secure stock, two-hand control, chip clearing and coast-down precautions. Do not import example dimensions as universal limits. |
| OSHA State Plans | Official overview of federal and State Plan jurisdiction and differing public-sector coverage, checked 2026-10-13. Individual state rules require a site-specific check. |
2. Scope and required inputs
Included scope
Plane the upper surface of secured bare wood with a two-hand corded portable planer, using shallow controlled passes and supported start/end positions.
Separate assessment
Stationary jointers or thickness planers, inverted mounting, painted or chemically treated stock, edge grooving and blade replacement are separate scopes.
| Input | Evidence needed |
|---|---|
| Review stock | Material and surface; Metal check; Size and allowance; Defect disposition. |
| Clamp and route | Clamp and bench; End support; Cable and chip path; Sole travel clearance. |
| Plane surface | Stock movement; Feed and load; Chip behavior; Surface change. |
| Clean and handoff | Chip collection; Tool power state; Stock result; Defect and receiver. |
No site measurements, equipment manuals for the actual installation, inspection records or signed technical approvals were supplied. Confirm the applicable requirements and actual product instructions before use; record each criterion with its units, source and equipment or work-area ID.
3. Eight-stage JSA
| Job stage | Hazards and effects | Failure factors | Technical and procedural controls | Site verification | P | S | R | A |
|---|---|---|---|---|---|---|---|---|
| 1. Review stock | 1. Blade breaks2. Stock ejects3. Dust exposure4. Poor finish | 1. Nail remains2. Stock too small3. Coating unknown4. Defect ignored | 1. Inspect for metal2. Verify usable dimensions3. Use bare known wood4. Reject defective stock | 1. Material and surface2. Metal check3. Size and allowance4. Defect disposition | ||||
| 2. Disconnect and inspect | 1. Blade cut2. Unexpected spin3. Loose blade ejects4. Electric shock | 1. Plug connected2. Switch on3. Fastening defective4. Cord damaged | 1. Unplug before access2. Verify full stop3. Inspect blade fixing4. Check supply protection | 1. Plug and switch2. Cutter stopped3. Blade and fasteners4. Cord and protection | ||||
| 3. Clamp and route | 1. Wood moves2. Cord cut3. Tool tips4. Hand at cutter | 1. Stock hand-held2. Cable in path3. End unsupported4. Clamp obstructs | 1. Clamp to stable bench2. Route cord clear3. Support start and end4. Keep clamps out of cut | 1. Clamp and bench2. End support3. Cable and chip path4. Sole travel clearance | ||||
| 4. Set depth and start | 1. Startup kick2. Dust inhalation3. Noise exposure4. Overload | 1. Blade touches stock2. Extraction absent3. Hearing ignored4. Excess depth | 1. Set suitable shallow cut2. Start with cutter clear3. Control dust and noise4. Keep two-hand grip | 1. Depth setting2. Starting sole support3. Dust and PPE4. Tool and grip | ||||
| 5. Plane surface | 1. Tool lifts2. Hand cut3. Chip strike4. Motor overload | 1. One-hand feed2. Base unsupported3. Blocked discharge4. Twisted force | 1. Maintain both handles2. Support sole through pass3. Watch chip discharge4. Use even shallow passes | 1. Stock movement2. Feed and load3. Chip behavior4. Surface change | ||||
| 6. Finish and park | 1. Coasting blade cut2. Tool jumps3. Surface damaged4. Hand underneath | 1. Set down rotating2. Foot trusted alone3. Poor landing4. Tool hand-caught | 1. Wait for complete stop2. Keep underside clear3. Use stable landing4. Follow parking method | 1. Cutter full stop2. Landing support3. Underside clearance4. Switch state | ||||
| 7. Hold impact or blockage | 1. Repeat blade strike2. Clearing cut3. Unexpected restart4. Damaged stock reused | 1. Finger in chute2. Power retained3. Impact ignored4. Depth only reduced | 1. Stop and disconnect2. Use clearing tools3. Inspect blade and stock4. Resolve cause before test | 1. Impact location2. Blockage and blade3. Repair disposition4. Controlled retest | ||||
| 8. Clean and handoff | 1. Chip cut2. Live-tool contact3. Defect reused4. Wrong dimension | 1. Cleaning plugged in2. Blade touched3. Fault not tagged4. Result unmeasured | 1. Clean while disconnected2. Use suitable tools3. Tag tool restrictions4. Record finished dimensions | 1. Chip collection2. Tool power state3. Stock result4. Defect and receiver |
P = likelihood; S = severity; R = risk under the site method; A = the site-defined acceptance/authorization decision. Complete only after actual assessment. Blank cells and checklist prompts are not completed inspections.
4. Fictional scenario and failure mechanisms
Retained AI-generated educational illustration from the source edition; not a real incident photograph, approved installation drawing or evidence of equipment suitability.
The scenario and record comparisons are fictional teaching examples, not records of real incidents, measurements, inspections, signatures or approvals.
| Item | Fictional scenario |
|---|---|
| Initial | A bare board is being planed. |
| Change | A metallic impact is followed by repeated surface ridges. |
| Failure | The operator proposes another pass at a shallower depth. |
| Outcome | A damaged blade or remaining fastener can cause further contact or fragment ejection. |
| Barrier | Stop fully, disconnect power and inspect tool and stock before an authorized repair and controlled restart. |
Why the controls matter
Check sole support at the beginning and end of the pass, not only the board length. A small workpiece must still allow clamping clear of the cutter and two-hand tool control; a helper hand cannot replace a clamp.
Releasing the switch does not prove that the cutter has stopped. Keep the underside clear, wait for full stop before setting the tool down and unplug before inspecting the underside or clearing chips.
New ridges after an impact may indicate blade damage or a hidden fastener. Reducing depth and making another pass does not remove that cause. Link the affected material, impact location, blade inspection and controlled test before restart.
Decision sequence
| Step | Decision |
|---|---|
| Known | A metallic impact is followed by repeated surface ridges. |
| Unknown | Actual condition, extent of damage and suitability of stock movement, feed and load remain to be established. |
| Hold | The operator proposes another pass at a shallower depth. |
| Evidence | Link stock movement, feed and load, chip behavior, surface change, impact location, blockage and blade to the affected equipment or work area. |
| Next | Stop fully, disconnect power and inspect tool and stock before an authorized repair and controlled restart. |
5. Conditional decisions and common errors
| Condition | Action | Evidence | Proceed when |
|---|---|---|---|
| Stock cannot clamp | Hold cutting | Clamp and sole path | Two-hand control possible |
| Impact or ridges | Stop and unplug | Stock and cutter inspection | Cause corrected |
| Chip blockage | Disconnect before clearing | Blade and chute condition | Safe discharge restored |
| Ready to set down | Keep underside clear | Cutter full stop | Tool stationary |
Similar appearance, different evidence
The scenario and record comparisons are fictional teaching examples, not records of real incidents, measurements, inspections, signatures or approvals.
| Comparison | Supported decision | Insufficient basis |
|---|---|---|
| Condition | Clamp and sole path | Stock cannot clamp has not been resolved. |
| Evidence | Blade and chute condition | A photograph or a completed-looking task without the relevant inspection record. |
| Release | Tool stationary | Completion of one step does not release the excluded tasks in section 2. |
6. Roles and responsibilities
| Role | Responsibility |
|---|---|
| Work supervisor | Assign the task boundary, stop authority, interfaces and emergency communication for portable electric wood planer. |
| Technical lead | Confirm Material and surface; Metal check; Size and allowance; Defect disposition. Resolve design and manufacturer limits before work. |
| Authorized crew | Apply Clamp and bench; End support; Cable and chip path; Sole travel clearance. Stop when the working arrangement changes. |
| Inspector / receiving lead | Review Stock movement; Feed and load; Chip behavior; Surface change. Transfer Chip collection; Tool power state; Stock result; Defect and receiver. |
Role labels allocate responsibilities; they do not confer a legal qualification. Verify the competence, training and authority required for the actual task.
Record and handoff perspective
| Stage | Record controls | Verification |
|---|---|---|
| Review stock | 1. Record material and surface2. Record metal check3. Record size and allowance | 1. Metal check2. Size and allowance3. Defect disposition |
| Clamp and route | 1. Record clamp and bench2. Record end support3. Record cable and chip path | 1. End support2. Cable and chip path3. Sole travel clearance |
| Set depth and start | 1. Record depth setting2. Record starting sole support3. Record dust and ppe | 1. Starting sole support2. Dust and PPE3. Tool and grip |
| Plane surface | 1. Record stock movement2. Record feed and load3. Record chip behavior | 1. Feed and load2. Chip behavior3. Surface change |
| Hold impact or blockage | 1. Record impact location2. Record blockage and blade3. Record repair disposition | 1. Blockage and blade2. Repair disposition3. Controlled retest |
| Clean and handoff | 1. Record chip collection2. Record tool power state3. Record stock result | 1. Tool power state2. Stock result3. Defect and receiver |
7. Hold points and record comparison
| Hold point | Evidence before release | Actual record |
|---|---|---|
| HP-0 Start | Plane the upper surface of secured bare wood with a two-hand corded portable planer, using shallow controlled passes and supported start/end positions. | |
| HP-1 Disconnect and inspect | Plug and switch; Cutter stopped; Blade and fasteners; Cord and protection | |
| HP-2 Set depth and start | Depth setting; Starting sole support; Dust and PPE; Tool and grip | |
| HP-3 Hold impact or blockage | Impact location; Blockage and blade; Repair disposition; Controlled retest | |
| HP-4 Clean and handoff | Chip collection; Tool power state; Stock result; Defect and receiver |
These are internal hold points, not issued permits. Recheck affected points after a change, fault or shift handoff; link the actual approval record.
Record comparison
The scenario and record comparisons are fictional teaching examples, not records of real incidents, measurements, inspections, signatures or approvals.
The boxes are static record prompts, not interactive or saved approvals. A tick does not establish suitability or permission to restart. Record the evidence, person, time and unresolved issues; retain the change history.
| Record | Insufficient | Record checklist |
|---|---|---|
| Review stock | "Checked" without target, criteria or result | □ Material and surface□ Metal check□ Size and allowance□ Defect disposition |
| Clamp and route | "Checked" without target, criteria or result | □ Clamp and bench□ End support□ Cable and chip path□ Sole travel clearance |
| Plane surface | "Checked" without target, criteria or result | □ Stock movement□ Feed and load□ Chip behavior□ Surface change |
| Clean and handoff | "Checked" without target, criteria or result | □ Chip collection□ Tool power state□ Stock result□ Defect and receiver |
8. Site checklist and emergency response
| Check | Result | Person / action |
|---|---|---|
| □ Review stock: Material and surface | ||
| □ Disconnect and inspect: Plug and switch | ||
| □ Clamp and route: Clamp and bench | ||
| □ Set depth and start: Depth setting | ||
| □ Plane surface: Stock movement | ||
| □ Finish and park: Cutter full stop | ||
| □ Hold impact or blockage: Impact location | ||
| □ Clean and handoff: Chip collection | ||
| □ Emergency access and handoff restrictions |
Stop work
Hold for uncertain stock clamping, cutter condition or electrical protection. Stop, wait and disconnect after impact, abnormal vibration, overload, new ridges or blocked chips. Do not inspect the underside while power remains connected.
Emergency response
Control access to fragments and the cutter. Stop and disconnect safely before approaching. Activate site first aid and call 911 for serious injury; tag the damaged tool and retain the affected stock for inspection.
9. Sources and review limits
Public-source review: 2026-10-13. Official regulation pages and specific technical references are distinguished below; no agency or manufacturer has approved this content.
| Source | Reviewed scope and limitation |
|---|---|
| OSHA 29 CFR 1910.243 | Portable powered tools; paragraph (a)(2)(iii) includes planers in its permitted control options. |
| CCOHS portable planers | Power disconnection, secure stock, two-hand control, chip clearing and coast-down precautions. Do not import example dimensions as universal limits. |
| OSHA State Plans | Official overview of federal and State Plan jurisdiction and differing public-sector coverage, checked 2026-10-13. Individual state rules require a site-specific check. |
No site measurements, equipment manuals for the actual installation, inspection records or signed technical approvals were supplied. Confirm the applicable requirements and actual product instructions before use; record each criterion with its units, source and equipment or work-area ID.
10. PDF guidance and FAQ
PDF A covers basic task controls; B focuses on technical failures; C covers supervision, records and handover. The article has eight stages with four items per main cell; each PDF has six key stages with three items per main cell. P/S/R/A, measurements, confirmations and signatures remain blank for actual site assessment.
Content group
jsa-portable-planer-wood
Can small stock be held in one hand?
No. Secure it so both hands control the planer and the sole remains supported.
May fingers clear the chute?
Disconnect power and use the specified tools and method after complete stop.
Is the maximum depth the normal setting?
No. Choose a pass suitable for stock, width, tool and feed conditions.
Does a parking foot replace coast-down checks?
No. Confirm full stop and use the actual model parking method.
Has a professional approved this JSA?
This reference material was written and revised with AI. It has not been verified or approved by a professional. Review by a suitably qualified professional and required site approval are necessary before field use.
11. Revision history and authorship
This reference material was written and revised with AI. It has not been verified or approved by a professional. Review by a suitably qualified professional and required site approval are necessary before field use.
Korean source created 2026-09-26. This US edition adapts the Korean source; earlier editorial revisions do not constitute professional approval of this edition.
| Date | Edition | Change | Review status |
|---|---|---|---|
| 2026-09-26 | Korean source v1.0 | Source editorial publication or revision; retained as provenance of the Korean edition. | Editorial record only; no professional approval of this US edition. |
| 2026-10-13 | 1.0 | US localization: preserve task judgments; replace Korean legal applicability with scoped US references. | AI editorial and output checks; no professional technical approval. |
