More film cannot restore crushed cartons, a damaged pallet or an unstable stacking pattern. Restrict access and transfer unstable loads to an authorized restacking process; never brace the load with a body while wrapping.
This reference material was written and revised with AI. It has not been verified or approved by a professional. Review by a suitably qualified professional and required site approval are necessary before field use.
Stop before proceeding
Stop for leaning or damaged loads, unsuitable pallets, insufficient walking space, mixed vehicle traffic, climbing, excessive reach, film breakage, carton deformation or pain. Keep unstable loads out of wrapping until their support and stacking are corrected.
1. Legal and technical scope
For warehouse general-industry work, 1910.176 addresses secure storage and housekeeping and 1910.22 addresses walking-working surfaces. These provisions do not specify a universal wrap count, film tension or manual handling weight. Construction activity needs its applicable Part 1926 assessment; the warehouse address alone does not classify all activities.
Confirm whether federal OSHA or an OSHA-approved State Plan covers this employer and worksite; state requirements and public-sector coverage can differ. Apply the task-specific provisions and limitations identified above.
| Basis | Application |
|---|---|
| OSHA 29 CFR 1910.176 | Stable storage, clear handling space and housekeeping; packaging approval is separate from transport securement. |
| OSHA 29 CFR 1910.22 | Inspect and correct walking-working surface hazards before work. |
| OSHA State Plans | Official overview of federal and State Plan jurisdiction and differing public-sector coverage, checked 2026-10-13. Individual state rules require a site-specific check. |
2. Scope and required inputs
Included scope
Manually wrap stable general packaged goods on a suitable floor-supported pallet using a film holder in a level indoor area; inspect, finish and hand over the wrapped pallet.
Separate assessment
Powered turntables or rotary arms, heat shrinking, climbing, suspended loads, hazardous or hot goods, rebuilding unstable stacks and vehicle cargo securement need separate procedures.
| Input | Evidence needed |
|---|---|
| Review pallet load | Item and weight; Pallet condition; Pattern and support; Overhang and damage. |
| Inspect film tools | Film specification; Holder condition; Cutter storage; Reach and frequency. |
| Wrap perimeter | Path and sightline; Film tension basis; Posture and reach; Carton deformation. |
| Handoff pallet | Final wrap state; Pallet and item IDs; Next movement plan; Receiver and holds. |
No site measurements, equipment manuals for the actual installation, inspection records or signed technical approvals were supplied. Confirm the applicable requirements and actual product instructions before use; record each criterion with its units, source and equipment or work-area ID.
3. Eight-stage JSA
| Job stage | Hazards and effects | Failure factors | Technical and procedural controls | Site verification | P | S | R | A |
|---|---|---|---|---|---|---|---|---|
| 1. Review pallet load | 1. Cartons collapse2. Pallet breaks3. Goods fall4. Worker struck | 1. Lean accepted2. Rating unknown3. Crushed base4. Overhang ignored | 1. Check stacking pattern2. Match pallet and load3. Hold damaged goods4. Control overhang | 1. Item and weight2. Pallet condition3. Pattern and support4. Overhang and damage | ||||
| 2. Prepare walking space | 1. Vehicle collision2. Trip and fall3. Body trapped4. Blind movement | 1. Traffic mixed2. Film on floor3. Narrow perimeter4. Poor light | 1. Separate vehicles2. Clear waste film3. Provide full perimeter4. Light travel direction | 1. Traffic boundary2. Floor condition3. Perimeter clearance4. Lighting and waste bin | ||||
| 3. Inspect film tools | 1. Hand cut2. Wrist strain3. Loss of balance4. High reach | 1. Blade exposed2. Holder unsuitable3. Film tears4. Tool too short | 1. Use safety cutter2. Match holder and film3. Check film condition4. Select reach aid | 1. Film specification2. Holder condition3. Cutter storage4. Reach and frequency | ||||
| 4. Secure film start | 1. Back strain2. Finger pinch3. Pallet slip4. Foot injury | 1. Deep bending2. Hand in gap3. Pallet climbed4. Poor footing | 1. Use planned low reach2. Keep hands outside gaps3. Stay on floor4. Stabilize stance | 1. Starting method2. Hand position3. Holder reach4. Footing and support | ||||
| 5. Wrap perimeter | 1. Backward fall2. Load shifts3. Trunk strain4. Carton crush | 1. Path unseen2. Excess tension3. Twisted reach4. Film overpulled | 1. See walking direction2. Follow wrap specification3. Reposition feet4. Watch load shape | 1. Path and sightline2. Film tension basis3. Posture and reach4. Carton deformation | ||||
| 6. Cut and finish | 1. Blade injury2. Film recoil3. Trip on tail4. Label hidden | 1. Cut toward body2. Stretched film released3. Tail hanging4. Markings covered | 1. Use directed safe cut2. Control film end3. Secure tail4. Retain labels | 1. Blade and hand path2. End tension3. Tail and waste4. Item identification | ||||
| 7. Hold tilt or pain | 1. Load collapse2. Repeated strain3. Unsafe manual catch4. Defect concealed | 1. More wrap added2. Pain ignored3. Load hand-braced4. Damage hidden | 1. Restrict load access2. Report discomfort3. Do not catch goods4. Assign recovery review | 1. Tilt and base damage2. Symptoms and exposure3. Restacking plan4. Changed method | ||||
| 8. Handoff pallet | 1. Load moves2. Wrong load moved3. Restrictions lost4. Defective pallet reused | 1. Appearance accepted2. ID missing3. No receiver4. Damage not tagged | 1. Check packaging criteria2. Match item ID3. Transfer movement limits4. Tag held loads | 1. Final wrap state2. Pallet and item IDs3. Next movement plan4. Receiver and holds |
P = likelihood; S = severity; R = risk under the site method; A = the site-defined acceptance/authorization decision. Complete only after actual assessment. Blank cells and checklist prompts are not completed inspections.
4. Fictional scenario and failure mechanisms
Retained AI-generated educational illustration from the source edition; not a real incident photograph, approved installation drawing or evidence of equipment suitability.
The scenario and record comparisons are fictional teaching examples, not records of real incidents, measurements, inspections, signatures or approvals.
| Item | Fictional scenario |
|---|---|
| Initial | A pallet is being wrapped manually. |
| Change | Lower cartons compress and the worker walks backward over discarded film. |
| Failure | Extra tension is used to hold the leaning load while back pain develops. |
| Outcome | The worker can fall or be struck by shifting cartons. |
| Barrier | Stop, exclude the load and resolve stacking, walking space and handling method before restart. |
Why the controls matter
More film cannot restore crushed cartons, a damaged pallet or an unstable stacking pattern. Restrict access and transfer unstable loads to an authorized restacking process; never brace the load with a body while wrapping.
Evaluate low bending, high reaching, twist, force and repetition together. Choose a suitable extended holder or revised method before using rest breaks as the only response. Do not stand on the pallet or make an improvised step.
Apply the validated packaging specification for the actual item, pattern and film. Tight-looking film is not evidence of internal support or vehicle securement. The receiver must assess the next movement and its restraints.
Decision sequence
| Step | Decision |
|---|---|
| Known | Lower cartons compress and the worker walks backward over discarded film. |
| Unknown | Actual condition, extent of damage and suitability of path and sightline, film tension basis remain to be established. |
| Hold | Extra tension is used to hold the leaning load while back pain develops. |
| Evidence | Link path and sightline, film tension basis, posture and reach, carton deformation, tilt and base damage, symptoms and exposure to the affected equipment or work area. |
| Next | Stop, exclude the load and resolve stacking, walking space and handling method before restart. |
5. Conditional decisions and common errors
| Condition | Action | Evidence | Proceed when |
|---|---|---|---|
| Load leaning | Exclude and hold wrapping | Pallet and stacking review | Stability restored |
| Film breaking | Stop pulling | Film and tension review | Method verified |
| Pain reported | Stop and report symptoms | Task and health review | Work suitability confirmed |
| Wrap complete | Inspect before release | Packaging and next movement | Restrictions transferred |
Similar appearance, different evidence
The scenario and record comparisons are fictional teaching examples, not records of real incidents, measurements, inspections, signatures or approvals.
| Comparison | Supported decision | Insufficient basis |
|---|---|---|
| Condition | Pallet and stacking review | Load leaning has not been resolved. |
| Evidence | Task and health review | A photograph or a completed-looking task without the relevant inspection record. |
| Release | Restrictions transferred | Completion of one step does not release the excluded tasks in section 2. |
6. Roles and responsibilities
| Role | Responsibility |
|---|---|
| Work supervisor | Assign the task boundary, stop authority, interfaces and emergency communication for manual pallet stretch wrapping. |
| Technical lead | Confirm Item and weight; Pallet condition; Pattern and support; Overhang and damage. Resolve design and manufacturer limits before work. |
| Authorized crew | Apply Film specification; Holder condition; Cutter storage; Reach and frequency. Stop when the working arrangement changes. |
| Inspector / receiving lead | Review Path and sightline; Film tension basis; Posture and reach; Carton deformation. Transfer Final wrap state; Pallet and item IDs; Next movement plan; Receiver and holds. |
Role labels allocate responsibilities; they do not confer a legal qualification. Verify the competence, training and authority required for the actual task.
Record and handoff perspective
| Stage | Record controls | Verification |
|---|---|---|
| Review pallet load | 1. Record item and weight2. Record pallet condition3. Record pattern and support | 1. Pallet condition2. Pattern and support3. Overhang and damage |
| Inspect film tools | 1. Record film specification2. Record holder condition3. Record cutter storage | 1. Holder condition2. Cutter storage3. Reach and frequency |
| Secure film start | 1. Record starting method2. Record hand position3. Record holder reach | 1. Hand position2. Holder reach3. Footing and support |
| Wrap perimeter | 1. Record path and sightline2. Record film tension basis3. Record posture and reach | 1. Film tension basis2. Posture and reach3. Carton deformation |
| Hold tilt or pain | 1. Record tilt and base damage2. Record symptoms and exposure3. Record restacking plan | 1. Symptoms and exposure2. Restacking plan3. Changed method |
| Handoff pallet | 1. Record final wrap state2. Record pallet and item ids3. Record next movement plan | 1. Pallet and item IDs2. Next movement plan3. Receiver and holds |
7. Hold points and record comparison
| Hold point | Evidence before release | Actual record |
|---|---|---|
| HP-0 Start | Manually wrap stable general packaged goods on a suitable floor-supported pallet using a film holder in a level indoor area; inspect, finish and hand over the wrapped pallet. | |
| HP-1 Prepare walking space | Traffic boundary; Floor condition; Perimeter clearance; Lighting and waste bin | |
| HP-2 Secure film start | Starting method; Hand position; Holder reach; Footing and support | |
| HP-3 Hold tilt or pain | Tilt and base damage; Symptoms and exposure; Restacking plan; Changed method | |
| HP-4 Handoff pallet | Final wrap state; Pallet and item IDs; Next movement plan; Receiver and holds |
These are internal hold points, not issued permits. Recheck affected points after a change, fault or shift handoff; link the actual approval record.
Record comparison
The scenario and record comparisons are fictional teaching examples, not records of real incidents, measurements, inspections, signatures or approvals.
The boxes are static record prompts, not interactive or saved approvals. A tick does not establish suitability or permission to restart. Record the evidence, person, time and unresolved issues; retain the change history.
| Record | Insufficient | Record checklist |
|---|---|---|
| Review pallet load | "Checked" without target, criteria or result | □ Item and weight□ Pallet condition□ Pattern and support□ Overhang and damage |
| Inspect film tools | "Checked" without target, criteria or result | □ Film specification□ Holder condition□ Cutter storage□ Reach and frequency |
| Wrap perimeter | "Checked" without target, criteria or result | □ Path and sightline□ Film tension basis□ Posture and reach□ Carton deformation |
| Handoff pallet | "Checked" without target, criteria or result | □ Final wrap state□ Pallet and item IDs□ Next movement plan□ Receiver and holds |
8. Site checklist and emergency response
| Check | Result | Person / action |
|---|---|---|
| □ Review pallet load: Item and weight | ||
| □ Prepare walking space: Traffic boundary | ||
| □ Inspect film tools: Film specification | ||
| □ Secure film start: Starting method | ||
| □ Wrap perimeter: Path and sightline | ||
| □ Cut and finish: Blade and hand path | ||
| □ Hold tilt or pain: Tilt and base damage | ||
| □ Handoff pallet: Final wrap state | ||
| □ Emergency access and handoff restrictions |
Stop work
Stop for leaning or damaged loads, unsuitable pallets, insufficient walking space, mixed vehicle traffic, climbing, excessive reach, film breakage, carton deformation or pain. Keep unstable loads out of wrapping until their support and stacking are corrected.
Emergency response
Move clear of the fall direction and prevent access. Do not catch or body-brace falling goods. Activate site response and call 911 for serious injury or immediate danger; controlled recovery must address the remaining unstable load.
9. Sources and review limits
Public-source review: 2026-10-13. Official regulation pages and specific technical references are distinguished below; no agency or manufacturer has approved this content.
| Source | Reviewed scope and limitation |
|---|---|
| OSHA 29 CFR 1910.176 | Stable storage, clear handling space and housekeeping; packaging approval is separate from transport securement. |
| OSHA 29 CFR 1910.22 | Inspect and correct walking-working surface hazards before work. |
| OSHA State Plans | Official overview of federal and State Plan jurisdiction and differing public-sector coverage, checked 2026-10-13. Individual state rules require a site-specific check. |
No site measurements, equipment manuals for the actual installation, inspection records or signed technical approvals were supplied. Confirm the applicable requirements and actual product instructions before use; record each criterion with its units, source and equipment or work-area ID.
10. PDF guidance and FAQ
PDF A covers basic task controls; B focuses on technical failures; C covers supervision, records and handover. The article has eight stages with four items per main cell; each PDF has six key stages with three items per main cell. P/S/R/A, measurements, confirmations and signatures remain blank for actual site assessment.
Content group
jsa-manual-pallet-stretch-wrapping
How many wraps are required?
Use the validated specification for the item, pallet pattern, film and next movement; no common count is supplied.
May film hold a leaning stack?
No. Isolate the unstable load and arrange safe restacking.
Can a worker stand on the pallet?
This scope excludes climbing; change the holder or packaging method.
Does wrapping secure freight for road transport?
No. Vehicle loading and cargo securement require their own assessment.
Has a professional approved this JSA?
This reference material was written and revised with AI. It has not been verified or approved by a professional. Review by a suitably qualified professional and required site approval are necessary before field use.
11. Revision history and authorship
This reference material was written and revised with AI. It has not been verified or approved by a professional. Review by a suitably qualified professional and required site approval are necessary before field use.
Korean source created 2026-10-03. This US edition adapts the Korean source; earlier editorial revisions do not constitute professional approval of this edition.
| Date | Edition | Change | Review status |
|---|---|---|---|
| 2026-10-03 | Korean source v1.0 | Source editorial publication or revision; retained as provenance of the Korean edition. | Editorial record only; no professional approval of this US edition. |
| 2026-10-13 | 1.0 | US localization: preserve task judgments; replace Korean legal applicability with scoped US references. | AI editorial and output checks; no professional technical approval. |
